Motor test benches

There are three motor test benches, which are appropiate for testing traction drives. They cover the power range of hybrid and electric vehicles.

The data of the test benches is listed below. If you are interested in cooperating with us, don't hesitate to contact Dr.-Ing. Alexander Stahl.

Motor test benches
Name max. Power max. Torque max. Speed
25 kW 190 Nm

1500 1/min

250 kW 540 Nm

15000 1/min

145 kW 270 Nm

18000 1/min

180 kW 143 Nm

12000 1/min

Motor Test Benches

Test Benches at the Institute of Electrical Engineering (Campus Süd)

Bild_Maschinensatz

To characterize and analyze the electrical-mechanical behaviour of electrical machines several test benches are used at the Elektrotechnische Institut. They can be mechanically arranged in various ways and equipped with the needed measurement sensors.



Test Benches at the Institute of Electrical Engineering - Hybrid Electric Vehicles (Campus Ost)

Contact: Prof. Dr.-Ing. Martin Doppelbauer
